Biograph Vision Quadra is the first whole-body PET/CT scanner designed to fit into your existing environment—expanding research opportunities and enabling clinical flexibility.
Molecular Imaging & Nuclear Medicine Systems
Biograph Vision Quadra
More Details
The power of a proven platform. The perspective of a large axial PET field of view. Biograph Vision Quadra takes the potential of PET/CT even further. Dynamically see vertex to thighs in a single position and deepen the dimension of your investigations. Whether you’re exploring new research questions or identifying the best clinical approach, with Biograph Vision Quadra, the answers are yours to find.
- Supports diagnostic precision across a range of clinical applications
- Incorporates features to help reduce scan time and manage radiation exposure
- Enables whole-body imaging within a single acquisition
Biograph Vision Quadra
Product Features
Explore the key features of Biograph Vision Quadra:
Cutting-Edge PET/CT Technology
- A long 106 cm axial PET field of view enables imaging from head to thigh in a single bed position
- Uses 32 detector rings with silicon photomultiplier (SiPM) detectors and 3.2 × 3.2 × 20 mm LSO crystals
Outstanding Clarity
- Extended axial field of view contributes to effective sensitivity up to around 1000 cps/kBq (measured values range ≈ 803–1000 cps/kBq depending on testing conditions)
- Time‑of‑flight performance of approximately 228 ps (depending on MRD mode), enabling excellent lesion detectability and image contrast
Reduced Scan Time and Radiation Exposure
- Longer axial field of view allows whole‑body dynamic imaging in a single position, supporting fast exams
- Capable of imaging with comparable signal‑to‑noise in as little as 2 minutes for head‑to‑pelvis scans in phantom studies
Comprehensive Whole-Body Imaging
- Supports dynamic tracer uptake tracking across major organs from vertex to thigh within one scan
- Axial coverage of 106 cm enables seamless scan ranges without repositioning
